SQ6 & SQ7 SC10 & SC11 Generator Maintenance Kit B - 40201761
SQ6 & SQ7, SC10 & SC11
£1,995.60
DESCRIPTION
SQ6 & SQ7 SC10 & SC11 Generator Maintenance Kit B – 40201761
This maintenance kit includes the following parts:
| Part description: | Quantity: |
| Pump Maintenance Kit | 1 |
| Oil filter including valve | 1 |
| Impeller & Gasket | 1 |
| Fuel filter WP | 1 |
| Exhaust switch kit | 1 |
| Diode replacement kit | 1 |
| Copper gasket ring 12X18X1.5 MM | 3 |
| Cooling water pump O-ring 56X3.5 | 1 |
| Cooling water pump Bearing 35X72X17 MM | 1 |
| Cooling water pump O-ring 72X2 Alternator bearing | 1 |
| Fuel Return Injector Gasket | 3 |
| Thermostat Housing Gasket | 1 |
| Glow Plug | 3 |
| Thermostat 76.5C | 1 |
| Injector Nozzle | 3 |
| V-belt | 1 |
| Rocker cover gasket | 1 |
| Pump Screws ZKGR M4X8 | 6 |
| Pump Cover | 1 |
| Coolant Temperature Switch 110C M16X1.5 NC | 1 |
| Oil pressure switch 0.5Bar – Single pole | 1 |
| Temperature switch M10X1 75C | 1 |
| Fuse blade 3A 32V Violet | 2 |
| Fuse blade 10A 32V Red | 1 |
| Capacitor 20uF 475V cable kit Class B 60Hz | 2 |
| Capacitor 25uF 475V cable kit Class B 60Hz | 1 |
| Capacitor 2uF 475V cable kit Class B 60Hz | 1 |
